Configure the perfect material handler to your needs

With a lower overall investment the Mantsinen cranes provide remarkably higher tons per hour capacity compared to traditional harbour cranes.

When evaluating the equipment capacity performance it is imperative to compare the capacity per hour instead of the maximum lifting capacity of the machines themselves.

The crane productivity depends on the material and application. We have optimal solutions from small river barge terminals to big ocean ports.

CABIN & CABIN ELEVATORS

EXCELLENT VISIBILITY AND ERGONOMICS

The large stainless steel cabin has been designed with the operator in mind and it is made to last even in the most demanding and corrosive environments. The silent and low vibration cabin creates the most comfortable work environment possible for the operator.

Experience Mantsinen Cabin now in 360˚

FRONT EQUIPMENT

Optimize the load and reach with right boom Configuration

SHORT VS .LONG
A wide range of boom and stick lengths are available to optimize the reach and lifting capacity.

CURVED VS. STRAIGHT
The curved boom is optimal for port operation when low reach to the bottom of the vessel hold is required. The straight boom provides beneficial geometry for terminal operations.

Undercarriages

Undercarriage for any site

CRAWLER
CRAWLER GANTRY
RUBBER TYRES
MOBILE GANTRY
FIXED
RAIL MOUNTED

CRAWLER GANTRY

Crawler gantry provides logistic freedom by allowing trucks or railcars pass through the crane. Additionally the machine cycle time and truck waiting times can be minimised due to the optimised swing angle.

MOBILE UNDERCARRIAGE

Solid tyre mobile undercarriage provides great mobility in this machine size. Simultaneously or individually controllable outriggers permit stable 360° operation with full loads even in demanding conditions.

MOBILE GANTRY UNDERCARRIAGE

Mobile gantry undercarriage combines great mobility and logistic freedom by allowing trucks or railcars pass through the crane. Also the cycle time can be minimized due to the optimised swing angle.

mantsinen power

ENGINE, MOTOR OR BOTH?

Electric powered

All Mantsinen machines are available fully electrified with all undercarriage options.

Electric versions provide full performance with low energy and maintenance costs and low noise level without exhaust emissions.

Diesel Powered

Volvo Penta diesel engines are known in the material handling industry for their high performance, low fuel consumption and durability.

DualPower

Mantsinen Dualpower is the first ever dual power concept in material handlers. It combines the best features of both electric motors and diesel engine. Resulting in a union of mobility, productivity and advanced environmental friendliness.

Learn more

Extras

Making MANTSINEN better

MANTSINEN INSIGHT™

With Mantsinen Insight you will improve your performance and remain at the leading edge of your business. It provides comprehensive information from individual material handling machines to a whole fleet.

By following over 150 outputs per a machine we will ensure, that you keep track of your operations, on-site and remotely – wherever you are.

Learn more

INNOVATIONS

The silhouette of a Mantsinen material handler is a common sight at the largest and busiest ports world-wide.

The roots of the Mantsinen machines are planted into the thick soil of practical operations. Thanks to our advanced technologies your work will be more precise, more productive and more profitable – with less effort.
